PINN-IT provide a wide variety of custom test fixtures depending upon customers requirements. We specialise in drilling and routing Acrylic, G10, Fibreglass, FR4, SRBF and SRBP using a Pluritec Minina CNC pcb drilling machine to ensure maximum accuracy. We cater for prototypes, small batch and production runs.
Click on any of the images below to see larger pictures
Manual location jig in grey PVC with sensor and tacho
Mains power-up automatic tester with tacho and wattage meter
Low cost manual jig with hinged and locking lid. Probe plate is also hinged for access to internal wiring.
Small manual jig using a ABS box with G10 pinbase and toggle clamp
Std          fixture customized for dual pcb probing.
